Description
Properties
- Excellent thermal insulation properties in winter.
- Ability to protect from overheating in summer.
- Water vapour open for a healthy internal environment.
- Manufactured with fresh softwood – sustainable climate protection through CO2 storage.
- Friction fits to adjoining components.
- Supports an environmentally friendly living environment.
- Ecological and environmentally friendly, fully recyclable.
- 0.036 W/mK.
Areas of Application
- Internal -
: Wall, floor & ceiling (friction fit in cavities & partitions, between roof rafters & floor joists)
Dimensions & Coverage
- 50 mm x 375 x 1190 (4.02m²/pk)
- 50 mm x 575 x 1190 (6.16m²/pk)
- 60mm x 375 x 1190 (3.57m²/pk)
- 60mm x 575 x 1190 (5.47m²/pk)
- 80 mm x 375 x 1190 (2.68m²/pk)
- 80 mm x 575 x 1190 (4.1 m²/pk)
- 100 mm x 375 x 1190 (1.79m²/pk)
- 100 mm x 575 x 1190 (2.74m²/pk)
- 140 mm x 375 x 1190 (1.79m²/pk)
- 140 mm x 575 x 1190 (2.74m²/pk)
Technical
Fire class according to EN 13501-1
E
Declared thermal conductivity λD [W/ (m*K)]
0.036
Density [kg / m³]
Approx. 60
Water vapour diffusion resistance value μ
2
Specific heat capacity c [J/(kg*K)]
2.100
Declared level of airflow resistance [(kPa*s) / m²]
≥ 5
Waste code (AVV)
030105 /170201, Waste disposal like timber or timber products
Ingredients
Wood fibres, polyolefin fibres, ammonium sulphate
Downloads
STEICOflex_036_en_i.pdf
