Description
Properties
- 3-layer, tear-resistant and flexible
- 2 integrated self-adhesive areas
- Airtight, highly vapour-permeable and resistant to driving rain
- Highly tear-resistant
- Outdoor exposure of up to 3 months possible
Areas of Application
- External -
: Roof as a sarking membrane
: Wall
Dimensions & Coverage
- 1.5m x 50m roll
Technical
Production and labelling
EN 13859
Fire behaviour
Class E according to EN 13501-1
Weight per unit area
165 g/m²
sd value
0.02 m
Temperature resistance
−40 °C to +80 °C
Maximum tensile force, longitudinal/transverse [N/5 cm]
290 / 210
Elongation at maximum tensile force, longitudinal/transverse [%]
50/90
Tear resistance, longitudinal/transverse [N]
220/280
Resistance to water penetration
W1
Resistance to water penetration after ageing
W1
Classification ZVDH
UDB-A, USB-A
Outdoor exposure
up to 3 months
Suitable as a temporary roof cover
up to 4 weeks
Resistance to air penetration [m³ / m²]
≤ 0,04 × h according to EN 12114
Roof pitch
≥ 10 ° depends on standard roof pitch of the roof covering
Downloads
STEICOmulti_UDB.pdf
