Description
Properties
- Applied to rafters or studs to improve insulation values.
- 3 fold functionality; insulation, wind tightness and weatherproofing.
- High ‘Summer Heat’ protection.
- Good sound insulating properties.
- Can be laid directly onto the rafters without additional support.
- Both easy to handle and work with.
- Water vapour open for healthy constructions.
- Exposure to the elements for up to 12 weeks on new build projects and 4 weeks for renovation projects for roof pitches over 16°.
- High insulation values, improving energy efficiencies.
- Reduces thermal bridging
Areas of Application
- External -
: Wall (applied to masonry or timber frame substrate with subsequent rendering, or masonry or timber cladding to the outside)
: Roof (above or below rafter where additional insulation is needed, in combination with Steico Flex)
Dimensions & Coverage
- 60 mm x 1325 x 600 (0.747m²)
- 60 mm x 1880 x 600 (1.067m²)
- 80 mm x 1325 x 600 (0.747m²)
- 80 mm x 1880 x 600 (1.067m²)
- 100 mm x 1325 x 600 (0.747m²)
- 100 mm x 1880 x 600 (1.067m²)
- 120 mm x 1880 x 600 (1.067m²)
Technical
Fire class according to EN 13501-1
E
Declared thermal conductivity λD [W/ (m*K)]
0.040
Water vapour diffusion resistance factor μ
3
Specific heat capacity [J / (kg*K)]
2,100
Compressive strength [kPa]
≥ 100
Tensile strength perpendicular to face ^ [kPa]
≥ 20
